Posted by Troy on August 22, 2010 under Microsoft, Sony, Windows 7 |
I was trying to backup some videos on my Sony PS3 the other day so I grabbed one of my old 80 GB hard drives. Of course the Sony PS3 didn’t recognize the NTFS file system, it needs to be FAT32. Simple enough, I thought, I’ll just backup the old files and format the drive as FAT32.
If you right click on the drive you and click Format there are two options
But there was no FAT32 option.
This was a job for Disk Manager not the simple format tool. Click Start and search for “Computer Management”. Then select the Device Manager.
Click on the drive you want to format and delete the old Volume. Make sure you have selected the correct drive.
Right-click on the disk to create a new volume. This will take you through a wizard that will allow you to select FAT32 to format the drive. The volume must be less than or equal to 32,768 MB.
Once I formatted the drive FAT32 the Sony PS3 recognized the device an I could backup the files.
If you want to get around the 32 GB limitation you could format the drive using Linux or a Linux Live CD like Knoppix.
Troy
Posted by Troy on August 7, 2010 under Blogging, Business, Business Intelligence, IT, Microsoft, Performance Management, Social Networking |
Well I am not sure how much sense it makes for a Blog to have a Facebook Page but I though I would try it out. I am always looking for new topics or issues to write about especially in the area of Business Intelligence or even day to day question on how to use Microsoft Office and SharePoint to enhance business activities. Feel free to post ideas or comments.
Troy Scott – Blog
Promote Your Page Too
Posted by Troy on under Microsoft, SQL Server, SharePoint, Visual Studio, Web, csharp |
When I first started building External Content Types in (ECT) SharePoint Foundation Server I used SharePoint Designer. SharePoint Designer is a good place to start if you are learning how build ECT’s. It does not require any .NET code and you can build a fairly decent application in little time especially if you have a solid relational database background. But I wanted to try build an External Content Type using Visual Studio 2010. In this case I am going to build a simple BDS Model based on the SalesLT.Customer table in the AdventureWorksLT2008R2 database.
First, lets start by creating an empty SharePoint 2010 Solution (C#) in Visual Studio 2010. Select File > New > Project from the file menu. In the Installed Template section under Visual C# > SharePoint > 2010 select the Empty SharePoint Project and name the project SPDev1. This will create an empty SharePoint project which we can add multiple projects to.
When you select Ok the SharePoint Customization will be displayed. Enter the the site you want to use for debugging the project and make sure you select “Deploy as a farm” solution:
Right-click on the SPDev1 project and select Add New Item:
Now Select Business Data Connectivity Model from the Add New Item list and name it AWLTCustomer. Once you enter the name of the model click Add:
 |
 |
| Add BDC Item |
BDC Solution |
When the BDC Model is added it is fully functional. If you Build the project it will compile without any errors.
You will notice that I named the Blog Post “BDC Models in Visual Studio 2010 for SharePoint Foundation Server 2010” and not “BDC Models in Visual Studio 2010 for SharePoint Server 2010” . If you created this project using SharePoint Server 2010 you can actually deploy this project to the debug site and it will create an BDC Model with an entity called Entity1. But if you are using SharePoint Foundation Server 2010 you will receive the following error when the project is deployed (Right-click the project and click Deploy):
Error 1 Error occurred in deployment step ‘Add Solution’: Failed to load receiver assembly "Microsoft.Office.SharePoint.ClientExtensions, Version=14.0.0.0, Culture=neutral, PublicKeyToken=71e9bce111e9429c" for feature "SPDev1_Feature1" (ID: 1a75169a-e716-4d4b-a43c-3c0cf032fc40).: System.IO.FileNotFoundException: …
In order to deploy a BDC Model to Foundation Server a Feature Event Receiver is required to publish the mode to the site:
Publish BDC Model project to SharePoint Foundation 2010 with Visual Studio 2010
The following post on one of the Microsoft Blog sites provides details on how create the Feature Event Receiver.
Deploy a BDC Model project to SharePoint Foundation 2010 using Visual Studio 2010
Basically you need to download the following file from the first link:
Feature Event Receiver (C#)
In the current project, add an Event Receiver to Feature1 by right-clicking Feature1 and select Add Event Receiver:
First copy the existing content of Feature1.EventReceiver.cs to a file using notepad. Next, replace the contents of Feature1.EventReceiver.cs with the contents of the file downloaded from the Microsoft site (FeatureEventReceiver.cs) (Ctrl-C, Ctrl-V). The details from this point on can be found in the Microsoft Blog post mentioned above (Deploy a BDC Model project to SharePoint Foundation 2010 using Visual Studio 2010), but I will provide some additional screenshots along with the steps.
We need to Add a reference to the MicrosoftBusinessData.dll. In order to do this you have to copy the dll from the GAC. Click Start > Run and enter the following:
- C:\Windows\assembly\gac_msil
Find the Microsoft.BusinessData folder and copy the Microsoft.BusinessData.dll to the following folder:
- C:\Program Files\Common Files\Microsoft Shared\Web Server Extensions\14\ISAPI
Next add the following references to the project:
 |
 |
| System.Web |
Microsoft.BusinessData.dll |
Set the BDC (SharePoint item property) which in our case is located in the AWLTCustomer model and set the following properties located under Feature Receiver Category:
- Assembly = Assembly = $SharePoint.Project.AssemblyFullName$
- Class Name = SPDev1.Features.Feature1.ImportModelReceiver
 |
 |
| Properties Before |
Properties After |
Set the Feature property by double clicking on Feature1.Feature and update the following property:
- Receiver Class = SPDev1.Features.Feature1.ImportModelReceiver
 |
 |
| Properties Before |
Properties After |
One last thing, we need to change the Namespace of the code that was copied into Feature1.EventReceiver.cs from BDCModelReceiver to SPDev1:
I have been writing this post while following Microsoft Blog. So, here is the moment of truth. After the last step we should be able to deploy the BDC model. Right-click on the project and click deploy or click F5 if you want to debug the solution. To view the content type you can open SharePoint Designer and navigate to the External Content Type sit object:
Before you can create an External list based on the new External Content Type the permissions must be set. Check out this post for setting the permissions using the SharePoint Central Administration site:
Setting Permissions for an External Content Type
Once the permissions have been set an External List can be created. In this example the External List is very basic and in fact the model has not been connected to the External table in the Adventure Works. But that is a topic for another post.
For more information on BCS check the Microsoft BCS Team Blog:
http://blogs.msdn.com/b/bcs/
Troy
Posted by Troy on August 6, 2010 under .net, IT, Microsoft, SharePoint, Visual Studio, Web |
This week I was creating my first SharePoint 2010 Sandboxed solution using Visual Studio 2010. I have successfully built and deployed other SharePoint projects on the server but I always used Farm based solution due to the requirements.
When I built the Sandboxed solution the project would build and package without any errors but when I tried to deploy it to the SharePoint site the following error occurred:
Error 1 Error occurred in deployment step ‘Activate Features’: Cannot start service SPUserCodeV4 on computer ‘SERVERNAME’ 0 0 SP2010Dev1
The error can be easily resolved by starting the Microsoft SharePoint Foundation Sandboxed Code Service which can be accessed through the Central Administration site in SharePoint. Open the Central Administration site and go to System Settings and click on Manage Service on server:
Check to see if Microsoft SharePoint Foundation Sandboxed Code Service is running, it should be stopped :
Start the service and try deploying the Sandboxed solution.
Thanks to Sergey Hyper Kravchenko for his post on the MSDN SharePoint discussion forum:
error occurred in deployment step ‘retract solution’ cannot start service SPUserCodeV4 on this computer
Troy
Posted by Troy on August 5, 2010 under .net, IT, Microsoft, Visual Studio |
If you are using Windows 7 or Windows Server 2008 and you try to create a project once Visual Studio has been opened you may receive the following message:
This task requires the application to have elevated permissions
If this occurs you have two options:
Right-click on the Visual Studio 2010 Shortcut
Hold down the SHIFT key and right click the shortcut:
Select Run as administrator and when you try to create project it will work. The downside of this approach is that you have to do this every time you want to run Visual Studio.
Set the Visual Studio Shortcut Properties to Run As Administrator
Hold down the SHIFT key and right click the shortcut:
Select properties and then click on the Compatibility tab. In the Privilege level section select the Run this program as an administrator check box.
Click Apply and when you double click the shortcut next time the program will run with Administrative privileges. However, you will receive a User Account Control notification when the program is run:
Troy
